HF - GASTRO 6

    is a premium oven designed for creative cooks: high quality components and small precautions intended to facilitate the work and let creation flow into wonderful new dishes.

    Types of cooking:

    • Hot air cooking from 30°C to 270°C

    • Combined cooking using hot air and steam from 30°C to 270°C to roast, braise and cook

    • core probe or Delta T cooking for low temperature cooking or for sous vide cooking

    We have combined stainless steel, glass, screen printing and technology in order to balance all esthetic requirements and easily integrate the oven into a variety of production spaces.

    Special functions2 speeds or inverter, automatic preheating, reducing outgoing vapors, triple tempered glass door, water collecting trays under the door and baking chamber, rapid baking chamber cooling, regeneration, Ventostop and programmed start.

    Controls:

    • MANUAL (on/off, temperature, time, steam and steam exhaust)

    • TOUCH SCREEN (7 inch touch screen interface with 90 multiphase programs)

    our strengths

    ELEGANT AND MODERN DESIGN

    HF-Gastro are designed to offer maximum flexibility and ease of use within a total quality oriented project: an elegant and refined look that betrays our commitment to quality, reliability and innovation.

    CHOICE: 4 in 1

    thanks to its various uses, with HF-Gastro you have an oven for hot air cooking, for steam cooking, for mixed cooking for ΔT cooking and for grill.
    The oven has special programs for regeneration and proofing. In addition, you can program the start and the recipe to have the oven ready at the beginning of the day.

    CLEANING

    for the cleaning of the HF-Gastro ovens we offer the following solutions:  integrated internal washing, retractile integrated shower or independent hand shower.

    The internal washing has 3 programs: fast - medium - hard.

    DETAILS

    quick evacuation system of steam in excess

    automatic reducing of outgoing vapors

    programmed start and rapid baking chamber cooling

    touch screen with quick access to memorized programs and logical step saving of new programs

    technical advantages

    STRONG STRUCTURE

    internal and external structure in stainless steel AISI 304

    welded cooking chamber with rounded corners

    central drain with siphon
    core probe predisposition

    RELEVANT DETAILS

    autoreverse motor and direction changing to guarantee the uniformity of baking

    intuitive 7 inch touch screen control with 90 programs

    triple glass and easily removable internal tray supports

    internal lightening of the baking chamber

    Ventstop: immediate stop of the fan when the door is opened in order to reduce the steam and heat loss from the baking room

    EASY TECHNICAL ACCESS

    easy access to components.

    quality components to minimize the number of technical interventions made to the oven during its working life

    easily changeable silicone gasket

    SAVINGS

    thanks to the installed power and thermal insulation with heat-sealed precompressed panels that keep the heat inside the cooking chamber.

    Steam is produced instantaneously in the cooking chamber using the amount strictly necessary to avoid wasting or high consumption.

    TECHNICAL FEATURES


    GASTRO 6 ELECTRIC   GAS
    number of trays 6 trays GN 1/1     6 trays GN 1/1
    oven external dimensions mm 950x846x830    mm 950x846x830
    power supply 380V - 3N - 50/60Hz 380V - 3N - 50/60Hz
    installed power 10,8 kW 9286 kcal/h
    number of motors  1 with autoreverse 1 with autoreverse
    space between trays 65 mm 65 mm
    water connection              1 x G 3/4"
              1 x G 3/4"
    water pressure                 2-6 bar
            (200-600 kPa)
                    2-6 bar
            (200-600 kPa)
    steam yes yes
    fan speed
    2 speeds
               2 speeds
